Dimplex SAHARA FIREPLACE 6903950000 - Manual (Page 10)

7
3
2
1
Figure 5
12. Mount the unit on the wall as shown (Figure 6).
Figure 6
Wall Bracket Supports
Wall Bracket
15.
13. Fix the unit in place by inserting 2 screws through 2 of
the 4 available back panel holes, and into the wall studs. If
studs are unattainable please use wall anchors. (Figure 7).
Figure 7
17.Replace glass assembly.
Panel Mounting Holes
