Assembly – Dixon 966004101 User Manual
Page 10
11
ASSEMBLY
7
CHUTE / HOOD INSTALLATION
Push upper chute through the gasketed opening in
1.
the cover assembly.
Rotate chute so the chute opening is downwards
2.
toward the container bags.
Hood Inlet
8
LEVELING MOWER DECK
Be sure deck is properly leveled for best mower
performance. See your mower operator’s manual for
instructions.
Rotate upper chute to point
downwards towards bags
