Getting to Know Your Dishwasher
6 Dacor ® Dishwasher
Getting to Know Your Dishwasher
Before You Start, Become Familiar with Your Dishwasher
IMPORTANT: See the Operating Your Dishwasher section, starting on page 14 for complete instructions on
how to use your dishwasher.
Parts of Your Dishwasher
™ Control Panel: Located on top of the door. The buttons control your dishwasher.
™ Detergent Dispenser: Automatically releases the soap during the wash part of the cycle (see
page 14).
™ Dishwashing Compartment: The compartment where tableware and cookware are loaded for
washing.
™ Door Switch: Located in the door. Automatically pauses dishwashing when the door is
opened.
™ In-Process Light: The blue in-process light shines on the floor below the dishwasher. It
flashes when the dishwasher is operating. It turns solid when the
selected cycle is complete. It turns off when the selected cycle is
complete and the door is opened and closed.
™ Filter System: Traps food and debris that could damage or plug up the mechanical
parts of your dishwasher. See page 20 for cleaning instructions.
™ Racks: The racks are coated with a durable coating that protects the finish of
tableware and cookware. They each have rows of adjustable tines that
allow you to make room for large items (see page 13).
™ Rinse Aid Dispenser: Automatically releases rinse aid during the rinse part of the cycle. Rinse
aid is a fluid that helps the dishes dry properly and helps prevent water
spots. The amount of rinse aid dispensed is adjustable (see page 15).
™ Silverware Basket: Use the silverware basket to hold silverware and kitchen utensils. It has
2 compartments that snap closed to hold small items (see page 11).
™ Spray Arms: The spray arms spray water on the dishes at high pressure to remove
soil.
™ Toe Kick Panel: Covers the internal mechanics of the dishwasher located below the door.
It must always be in place during operation.
Toe Kick Panel
Blue In-Process Light shines on floor
below dishwasher
