SETUP MENU DESCRIPTIONS AND OPERATION
Following are explanations of the many settings that can be changed to customize the operation of
your Rear Seat Entertainment system. To change the settings described, follow the directions in the
on-screen menus section or the special instructions in each menu.
SELECTION DESCRIPTION AND OPERATION
CHANNEL (TVM300 ONLY) ■ Change TV channels.
■ Use CHDN/CHUP buttons to change channels
DIMMER ■ Change illumination for day or night viewing.
■ HIGH - Sets illumination for viewing in daylight.
■ MEDIUM - Sets illumination for viewing in twilight.
■ LOW - Sets illumination for viewing at night.
PICTURE ■ Select to adjust picture.
Note: To adjust use the ■ BRIGHTNESS - Adjusts picture brightness.
monitor’s UP/DOWN buttons ■ COLOR - Adjusts picture color.
or the remotes (+)/(-) ■ CONTRAST - Adjusts picture contrast.
buttons. ■ HUE - Adjusts picture hue (NTSC only).
SCREEN (RVM700 ONLY) ■ WIDESCREEN (16:9) - Wide screen videos will appear
undistorted and fit the full screen. Normal videos
(4:3) will be stretched from the sides to fit the full
screen and appear distorted.
■ NORMAL (4:3) - Normal videos will appear undistort-
ed in the center with bars at both sides. Wide
screen videos (16:9) will shrink to fit into the same
area and make the image appear taller.
■ PROGRESSIVE - Normal videos (4:3) will fit the full
screen. The center of the picture will appear normal
with the edges stretched to fit the full screen and
appearing slightly distorted.
■ ZOOM - Normal videos (4:3) will fit the full screen.
The picture will be zoomed in to fit the full screen
from side to side. The picture will remain undistort
ed, but a portion of the top and bottom will be cut off.
OSD COLOR ■ Select to change the color of the on-screen display.
■ WHITE - Changes the OSD to White.
■ GREEN - Changes the OSD to Green.
■ BLUE - Changes the OSD to Blue.
