7
© 2001 Directed Electronics, Inc.
MONITOR DESCRIPTION
1. Screen - TFT active matrix LCD screen.
2. Power/Source button - Press to turn the
monitor on/off or change video source.
■ Press to turn the monitor on.
■ Press for more than three seconds to
turn the monitor off.
■ Press for less than three seconds
when on to change the source.
3. IR remote input - For remote control
operation.
4. Up/down buttons - Adjusts programming
when MODE is pressed. Also adjusts
TV/CATV channel up and down when
TVM300 module is connected.
5. Mode button - Changes up/down buttons
functions.
6. LED indicator light - When turned on the
light is blue; when on standby the light is
red.
MAINTENANCE
Keep the monitor clean and free of dust and
moisture and it will provide years of trouble free
operation. Do not allow any cleaning fluids on
the monitor screen or bezel, they may contain
chemicals that can harm the finish and diminish
the picture quality.
To clean the monitor, simply use a soft, dry
cloth and gently wipe away any dirt. Avoid
applying too much pressure to the screen when
cleaning as it can result in damage.
Basic Operation
5 6 4 2 1 4 3
