ASSIGN SOURCE NAMES MENU

NOTE: In this menu use the monitor’s MODE button or the remote’s MENU button to toggle through the available

choices for source names.

SELECTION

DESCRIPTION AND OPERATION

SOURCE 1: AV1

Select to change the name of source 1 from the source
names list at the end of this section.

SOURCE 2: AV2

Select to change the name of source 2 from the source
names list at the end of this section.

SOURCE 3: AV3

Select to change the name of source 3 from the source
names list at the end of this section.

WRITE TO SYSTEM

■

Highlight WRITE TO SYSTEM, press the monitor’s
MODE button or the remotes MENU button to
enter the system changes.

■

WRITING TO SYSTEM will be displayed.

■

WRITE SUCCESSFUL - Information entered successfully.

■

WRITE FAILED - Information not entered successfully.

ASSIGN TRIGGER NAMES MENU

NOTE: In this menu use the monitor’s MODE button or the remote’s MENU button to toggle through the available

choices for zone names.

SELECTION

DESCRIPTION AND OPERATION

ZONE 1

Select to change the name of zone 1 from the zone names
list at the end of this section.

ZONE 2

Shock sensor - Can not be changed.

ZONE 3

Door switch - Can not be changed.

ZONE 4

Select to change the name of zone 4 from the zone names
list at the end of this section.

ZONE 5

Ignition - Can not be changed.

ZONE 6

Select to change the name of zone 6 from the zone names
list at the end of this section.

ZONE 7

Select to change the name of zone 7 from the zone names
list at the end of this section.
