4-3 Set sensor
The system supports up to four sensor inputs.
☞ OPTION : Able to use up to 16 alarms and sensors when using separate “extended alarm
sensor box”.
How to set menu : retrieve menu -> EVENT -> SENSOR
▶ Select Use Y/N.
(Use) (Not use)
▶ Input method : Choose between Normal Open and Normal Close.
• N/Open (NORMAL OPEN) : Generate signal when contact point closes after it was normally
left open
• N/Close (NORMAL CLOSE) : Generate signal when contact point opens after it was normally
left closed
▶ Linked channels: Able to use by linking a sensor to multiple channels.
(Not use) (Use)
