OnLine Power Mini Power Wave - Manual (Page 12)

6005-100 Rev A
3
2.2 System Configuration
The UPS device and the internal backup battery make up the system. Depending on the site and load
requirements of the installation, certain additional options are available as a tailored solution.
Planning a UPS system, the following should be taken into consideration:
The total demand of the protected system shall dictate the output power rating (Watts). Allow a margin for
future expansion or calculation inaccuracies from measuring power requirements.
Backup time at the indicated power rating is 90 minutes.
The following UPS models are available
Wall/Floor Mountable Lighting Inverter
90 minute battery back up (Batt. 24 VDC)
Total/
WATT
Model
Numbers
Input/Output
Voltages BTU/ Hr
Cabinet Dimension
(W ” xH ” xD ” )
WM.20A01OP 120V/120V 216
WM.20R01OP 277V/120V 233
WM.20R25OP 277V/277V 233
200W
WM.20A25OP 120V/277V 233
24 X 17 X 9.5
WM.30A01OP 120V/120V
305
WM.30R01OP 277V/120V
353
WM.30R25OP 277V/277V
353
300W
WM.30A25OP 120V/277V
353
“
WM.49A01OP 120V/120V 499
WM.49R01OP 277V/120V 543
WM.49R25OP 277V/277V 543
490W
WM.49A25OP 120V/277V 543
“
(NOTE)
**
BTU/HR ARE APROX. NUMBER WITH TOLERANCE ± 15% FOR ALL MODELS
