Denon PMA-2000IVR - Manual (Page 10)

10
4 REMOTE CONTROL OPERATION
The accessory Remote Control Unit is used to control the amplifier from a convenient distance.
(1) Inserting the Dry Cell Batteries
1. Remove the battery cover on the Remote Control Unit.
Notes on Battery Usage
• RC-858 uses the size R03 (AAA) dry cell batteries.
• The batteries will need to be replaced approximately once a
year. This will depend upon how often the Remote Control
Unit is used.
• If, in less than a year from the time new batteries were
inserted, the Remote Control Unit fails to operate the Amplifier
from a near-by position, it is time to replace the batteries.
(The included battery is only for verifying operation. Replace it
with a new battery as soon as possible.)
• Insert the batteries properly, following the polarity diagram
inside the battery compartment.
• Batteries are prone to damage and leakage. Therefore:
• Do not mix new batteries with used ones.
• Do not mix different types of batteries.
• Do not jumper opposite poles of the batteries, expose them
to heat, break them open, nor expose them to open fire.
• If the batteries have leaked, remove any traces of battery fluid
from the battery compartment wiping thoroughly with a dry
cloth. Then insert new batteries.
2. Insert two dry cell batteries as shown in the diagram on
the battery supply unit.
3. Replace the battery cover.
(2) Directions for use
• Operate the Remote Control Unit while pointing it towards the
Remote Control Sensor on the Amplifier as shown in the
diagram on the left.
• The Remote Control Unit can be used at distances up to about
8 meters in a straight line from the amplifier. This distance will
decrease if there are obstructions blocking the infra-red light
transmission or if the Remote Control Unit is not directed
straight at the amplifier.
Note on operation
• Do not press the operating buttons on the Amplifier and the Remote Control Unit at the same time. This will cause misoperation.
• Operation of the Remote Control Unit will become less effective or erratic if the infrared Remote Control Sensor on the Amplifier is
exposed to strong light or if there are obstructions between the Remote Control Unit and the sensor.
• In case you operate a VCR, TV or other components by remote control, do not operate buttons on two different remote control units
at the same time. This will cause misoperation.
Besides being able to operate the PMA-2000 IVR Integrated-amplifier with this Remote Control Unit,
you can also operate a DENON CD player from this handy Remote Control Unit.
Approx. 8 meters
30°
30°
