806 and 807 Audio Selector Panels
SM806 Installation and Operation Manual
Section 2 Rev: 1.00 Issue 4 Page 2-4
ENG-FORM: 805-0115.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
2.6 Accessories Required But Not Supplied
The aircraft connectors required to complete the installation are:
Item Ident
Description Part No.
External Connector 1 J1 61 Pin Circular, Female, Crimp D38999/26WJ61SN
Models 806 and 807
External Connector 2
J2 Pin Circular, Female, Crimp, Alt Keying D38999/26WJ61SC
Models 806 only
Backshell, Strain Relief
N/A N/A M85049/38-25W
Models 806 and 807
2.7 Installation Drawings
DOCUMENT REV. DESCRIPTION TYPE SERIAL NO.
806-000
806\000\403-0 1.00 Audio Selector Panel Interconnect All
806\000\403-1 1.00 Audio Selector Panel Interconnect All
806\000\403-2 1.00 Audio Selector Panel Interconnect All
806\000\403-3 1.00 Audio Selector Panel Interconnect All
806\000\405-0 1.00 Audio Selector Panel Connector Map All
806\000\952-0 1.01 Audio Selector Panel Custom Mechanical Installation Up to 1126
806\000\952-0 1.02 Audio Selector Panel Custom Mechanical Installation 1127 and up
806\521-0 1.00 Audio Selector Panel Environmental Qualification Form All
807-000
807\000\403-0 1.00 Audio Selector Panel Interconnect All
807\000\403-1 1.00 Audio Selector Panel Interconnect All
807\000\403-2 1.00 Audio Selector Panel Interconnect All
807\000\405-0 1.00 Audio Selector Panel Connector Map All
807\000\952-0 1.01 Audio Selector Panel Custom Mechanical Installation All
807\521-0 1.01 Audio Selector Panel Environmental Qualification Form All
Section 2 ends following the above documents
