SM270 Rev. 4.10 Model 270 Universal Interface Amplifier Manual
1.4.1.4
Overall Specifications
SPECIFICATION Description
Isolation & Crosstalk
≤-70 dB (-80 dB typical)
Noise <-80 dB (-80 dB typical)
Total Harmonic
Distortion (THD+N) <1% (typical)
Frequency Response Flat to within 3 dB from 300 Hz to 6000 Hz
TSO Compliance: TSO-C50c, RTCA/DO-214
1.4.2 Physical Specifications
Height 1.37" (34.91 mm)
Depth 2.50" (63.50 mm)
Width 4.50" (114.30 mm)
Weight 0.40 lbs (0.18 kg)
Mounting Four #10 mounting screws into 0.203" diameter
holes spaced 4.00" (W) by 1.80" (D) on centre
Enclosure Finish Chromate Film in accordance with MIL-C-5541
Connector (P1) One 25-pin 'D' submin connector with locking posts
1.4.3 Environmental Specifications
Operating Temperature -55 ° to +70°C
Altitude up to 70,000 feet
Qualification:
DO-160D Environmental Categories: [(A2)(F2)-]BBB[(TRY)(UG)]XXXXXXZ[BZ]AZAUM[XXC2]XXA
Note: Refer to Environmental Qualification Form in Section 2 of this Manual for
complete details of the environmental categories.
1.5 Unit Nomenclature
Derivative information can be found in the applicable manual supplement, or by contacting
NAT Ltd.
End of section 1
Dec 12, 2006 Page 1-5
