PTA12-300 POTS Telephone Adapter with NVIS Display
SM55-3 Installation and Operation Manual
Section 2 Rev: 1.01
Issue 4 Page 2-4
ENG-FORM: 805-0121.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
2.6 Accessories Required But Not Supplied
Installation kit p/n D25SV-IKC (crimp) is required to complete the installation. The kit consists of the
following:
Quantity Description NAT Part No.
1 D-min 25 Socket Housing 20-21-025
25 MS Crimp Socket 20-26-901
1 25 Pin JVL Hood/Locklever 20-29-250
2.7 Installation Drawings
Insert into the following list all applicable Installation Drawings (including a minimum of 403, 405, 922 or
952 and if available the 404, 521 and 905). See following example.
DOCUMENT REV.
DESCRIPTION TYPE
PTA12-300
PTA12\300\403-0 1.00 POTS Telephone Adapter with NVIS Display Interconnect
PTA12\300\403-1 1.00 POTS Telephone Adapter with NVIS Display Interconnect
PTA12\300\403-2 1.00 POTS Telephone Adapter with NVIS Display Interconnect
PTA12\300\403-3 1.00 POTS Telephone Adapter with NVIS Display Interconnect
PTA12\300\403-4 1.00 POTS Telephone Adapter with NVIS Display Interconnect
PTA12\300\405-0 1.00 POTS Telephone Adapter with NVIS Display Connector Map
PTA12\300\905-0 1.00 POTS Telephone Adapter with NVIS Display Faceplate
PTA12\300\922-0 1.10 POTS Telephone Adapter with NVIS Display Mechanical Installation
STX100-000
STX100\000\403-6 1.00 STX100 GLOBALSTAR™ Satphone Receiver Interconnect
STX100\000\403-7 1.00 STX100 GLOBALSTAR™ Satphone Receiver Interconnect
Section 2 ends following the above documents
