PTA12-100 POTS Telephone Adapter with Display
SM55-2 Installation and Operation Manual
Section 1 Rev: 1.00 Issue 4 Page 1-5
ENG-FORM: 800-0114.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
HLD (Hold Status)
On Hold LED on
Off Hold
LED off
LNK (satcom link)
Link Established LED on
Link Down
LED off
SYS (satcom system)
Available for Voice LED on
Busy LED
off
1.4.2 Physical Specifications
Height 1.52" (38.6 mm)
Depth
4.17" (105.9 mm) max. behind panel
Width
5.77" (146.6 mm) in front of panel
4.82" (122.4 mm) behind panel
Weight
0.80 lbs (0.36 kg)
Mounting Dzus Mounting (four fasteners)
Front Panel
Aluminum with polycarbonate label and elastomeric keypad
Silicone rubber, tactile push-buttons backlit by amber LEDs
Front panel bezel is not backlit
Display 16 5x7 pixel characters with green polarized filter
Material/Finish Chassis & cover are 5052-H32 brushed aluminum with chromate
conversion finish
Connectors
One male filtered 25 pin D-submin with Positronics V5 locking
tabs
