PTA12-100 POTS Telephone Adapter with Display
SM55-2 Installation and Operation Manual
Section 3 Rev: 1.00 Issue 4 Page 3-9
ENG-FORM: 806-0112.DOT
CONFIDENTIAL AND PROPRIETARY TO NORTHERN AIRBORNE TECHNOLOGY LTD.
Button Call Mode Function Edit Mode Function
1 DTMF tone 1 transmitted and digit 1 displayed 1, -, ., or / displayed
2 DTMF tone 2 transmitted and digit 2 displayed 2, A, B or C displayed
3 DTMF tone 3 transmitted and digit 3 displayed 3, D, E or F displayed
4 DTMF tone 4 transmitted and digit 4 displayed 4, G, H or I displayed
5 DTMF tone 5 transmitted and digit 5 displayed 5, J, K or L displayed
6 DTMF tone 6 transmitted and digit 6 displayed 6, M, N or O displayed
7 DTMF tone 7 transmitted and digit 7 displayed 7, P, Q, R or S displayed
8 DTMF tone 8 transmitted and digit 8 displayed 8, T, U or V displayed
9 DTMF tone 9 transmitted and digit 9 displayed 9, W, X, Y or Z displayed
0 DTMF tone 0 transmitted and digit 0 displayed 0 or character space displayed
* DTMF tone ½ transmitted and char * displayed Only ← available (moves cursor 1 position
to left or selects delete data of a selected
address)
# DTMF tone # transmitted and char # displayed Only → available (moves cursor 1 position
to right or selects edit data of a selected
address)
ESC No function Cancels current activity during store and
returns to Default mode
HOOK Toggles the hook switch to inactive, and enters
Default mode Activates the hook switch and enters Call
mode
HOLD Mutes mic and phones No function
REDIAL Retrieves the last number dialed, displays it, and
calls the number
No function
FLASH Takes hook switch inactive for selected flash
pulse duration
No function
UP Increases the phones volume Scrolls up through the list of stored
numbers
DOWN Decreases the phones volume Scrolls down through the list of stored
numbers
BRT Increases display brightness and wraps around
from max to min brightness Increases display brightness and wraps
around from max to min brightness
ENTR Sends a number dialed from Default or Recall
mode Accepts a data item or completes a
sequence.
Table 2
Call and Edit Modes
Section 3 ends
