3GHD-OE / 3GHD-OE-2 Rev. F
nevion.com | 18
7.2 Single converter
FLP4.0 block for single converter is listed below.
7.2.1 RCL 0
Reclocker for output 1.
::= 'rcl'
::= ['en'|'mute'|'bypass'] ['lock'|'lol']
['Mbps'] ['asi'|'sdi'|'hdsdi']
['abp' 'on'|'off'] ['rate' 'man'|'auto']
::= ||
::= 'en'|'mute'|'bypass'
::= 'abp' 'on'|'off'
7.3 Dual converter
FLP4.0 block for dual converter is listed below.
7.3.1 PIN 1
Optical input 1. Long haul version supports optical level.
::= 'pin'
::= ['cd'|'ncd'] ['dBm']
7.3.2 CHO 0
Input select for output 1.
::= 'cho'
::= [] ['size' 2] []
[]
::= |
::= 'auto'|'man'
::= 'pri'
::= 'pos' 'auto'|('man' )
::= 'pri'
