4.2 Specifications
Optical 10G input/output
See relevant SFP+
datasheet
Electrical SDI inputs
Number of inputs 6
Connectors 75 Ohm BNC
Equalization Automatic;
>275 m @270 Mbps w/Belden 8281, with BER < 10E-12
>100 m @1485 Mbps w/Belden 1694A, with BER < 10E-12
Input Return loss >15 dB, 5 MHz -1.5 GHz
Jitter tolerance SD limit:
10 Hz-1 kHz: >1 UI
10 kHz
– 5 MHz: >0.2 UI
HD limit:
10 Hz-100 kHz: >1 UI
100 kHz
–10 MHz: >0.2 UII
Electrical SDI outputs
Number of outputs 6
Connectors 75 Ohm BNC
Output Return loss >15 dB, 5 MHz -1.5 GHz
Output signal level 800 mV +/- 10%
Output signal rise / fall time
20% - 80% SD limit: [0.4 ns
– 1.5 ns]; <0.5 ns rise/fall var.
HD limit: <270 ps, <100 ps rise/fall var.
Amplitude overshoot <10%
Output timing jitter SD: <0.2 UI
HD: <1 UI
Output alignment jitter SD: <0.15 UI
HD: <0.15 UI
Supported standards
SD, 270 Mbps SMPTE 259M, SMPTE 272M-AC
HD, 1485 Mbps SMPTE 292M, SMPTE 274M, SMPTE 291M, SMPTE 296M,
SMPTE 299M
ASI EN50083-9
Power consumption (+5 VDC)
Maximum power, at 50°C 12.2 W
Subtract 0.5 W from the power figure above if the boards are used without
the piggy-back fan modules. This requires the use FR202 Flashlink frame
or of a rack with built-in fans for cooling!
