2 Channel 5 Off: Channel 5 is output
On: Channel 5 is input
3 Channel 6 Off: Channel 6 is output
On: Channel 6 is input
4 Channel 7 Off: Channel 7 is output
On: Channel 7 is input
5 Channel 8 Off: Channel 8 is output
On: Channel 8 is input
6 Switch matrix Off: Switch matrix is in diagonal formation
On: Switch matrix is in alternate diagonal formation
7 - No function
8 OVR Off: GYDA mode
On: Manual mode
Table 3: DIP switches and their functions
3.3 With GPIO pins
There is only one GPIO pin that is an input to the module. This provides another way to shut
down the laser. This is intended as a safety feature when work is being done on the rear of
a live Flashlink rack.
When the GPIO pin is pulled to ground, the laser is disabled. See Table 1: Connector
functions in ch. 1 for GPIO pin-out.
