6. TECHNICAL SPECIFICATIONS
AUDIO INPUT
Connectors XLR Type RF filtered, servo-balanced input
Impedance 2 kOhms balanced, 1 kOhm unbalanced
Max. Input Level +4dBu balanced and unbalanced CMRR typ. 40dB, >55dB @ 1 kHz
1/4" jack
AUDIO OUTPUT
Connectors XLR and 1/4" jack
Electronically servo-balanced output stage (optional transformer-balanced).
Automatic level correction for unbalanced use (6 dB).
Impedance 60 Ohms balanced, 30 Ohm unbalanced
Max. Output Level +21dBu, +20dBm balanced and unbalanced
SYSTEM SPECIFICATIONS
Bandwidth 18 Hz to 30 kHz, +/-3dB
Signal-to-noise ratio >100dB, unweighted, 22 Hz to 22 kHz
THD 0.008 % typ. @ +4dBu, 1 kHz, Gain 1
0.04 % typ. @ +20dBu, 1 kHz, Gain 1
IMD 0.01 % typ. SMPTE
Crosstalk <-100dB, 22 Hz to 22 kHz
POWER SUPPLY
30VAC by custom adapter or 24 VDC by custom battery pack
ADAPTER
Mains voltages
USA/Canada ~ 120 V AC, 60 Hz
U.K./Australia ~ 240 V AC, 50 Hz
Europe ~ 230 V AC, 50 Hz
General Export Model ~ 100-120 V AC, ~ 200-240 V AC, 50-60 Hz
Power consumption 10 Watts
PHYSICAL
Dimension HALF RACK STANDARD 240mm x 44 mm x 110 mm
Net weight 1 kg around
Shipping weight 2 kg around
