Fig. 4.2 Back panel connections
1) MAIN POWER SUPPLY SOCKET. Use only original power supply. Read carefully
the SAFETY INSTRUCTIONS before connecting the device.
2) This clip is the holder for the power supply cord, fix the cable to avoid undesired
unplugging.
3) The CH2 BALANCED SPLIT OUT is the +4 dBu XLR output of the CH2. It is
possible to connect both in balanced and in unbalanced mode this output.
4) These are the unbalanced outputs of the device. Their standard level is –10 dBV.
5) The CH1 BALANCED SPLIT OUT is the +4 dBu XLR output of the CH2. It is
possible to connect both in balanced and in unbalanced mode this output.
6) The LIMITER THRESHOLD control allows setting the threshold level of the limiter
stage of the device. One set every audio signal that will over-pass the threshold will
be padded. If the Limiter is not desired set the Limiter Threshold control to max.
