13 - PMS USER’S MANUAL
6. TECHNICAL SPECIFICATIONS
AUDIO INPUT
DIRECT input
XLR + ¼” Connectors
Type RF filtered, servo balanced input
XLR input impedance: 14 Kohm selectable balanced
Jack input impedance: 400 Kohm balanced
Max. input level for XLR input +10 dBu balanced and unbalanced
Max. input level for jack input +30 dBu balanced and unbalanced
CMRR typ. 40 dB, >55 dB @ 1 kHz
Internal Phantom power possibility +16 Volts
MAIN, AUX1, AUX2 input
Male XLR Connectors
Type RF filtered, servo balanced input (line audio transformer optional)
Impedance 24 Kohms balanced, 12 Kohms unbalanced
Max. input level +26 dBu balanced
CMRR typ. 40 dB, >55 dB @ 1 kHz
SYSTEM SPECIFICATIONS
Frequency response 10 Hz to 50 kHz, +0 - 3 dB
S/N ratio >105 dB referred to MAIN IN, max out, unweighted, 22 Hz to 22 kHz
THD 0.005 % typ. @ +4 dBu, 1 kHz, Gain 1
POWER AMPLIFIER
Max. output power +22 dBu
Min. output impedance 32 Ohms
Max. gain +44 dB referred to line input
POWER SUPPLY
35 VAC by dedicated adapter or 36 VDC by dedicated battery pack
ADAPTER
Mains voltages USA/Canada ~ 120 V AC, 60 Hz
U.K./Australia ~ 240 V AC, 50 Hz
Europe ~ 230 V AC, 50 Hz
General Export Model ~ 100-120 V AC, ~ 200-240 V AC, 50-60 Hz
Power consumption 10 Watts
PHYSICAL
Dimension HALF RACK STANDARD 240mm x 44 mm x 110 mm
Net weight 1 kg around Shipping weight 2 kg around
