Installation instructions.

Typical Installation Illustration

Optional 3-Valve Bypass Installation Illustration

6

Soft water

Hard water to
outside faucets

MAIN W

ATER PIPE

Hard water

NOTE: See Drain Hose
Connections section.

24V transformer

120-volt outlet

Hard water

Soft water

From softener
outlet

To softener
inlet

Hard water

Soft water

From softener
outlet

To softener
inlet

CROSS-OVER

Use if water supply flows from the left.

Include single or 3-valve bypass.

MAIN W

ATER PIPE

Soft water

Hard water

24V transformer

120-volt outlet

Bypass valve

Hard water to
outside faucets

Inlet valve

Outlet valve

3-valve bypass system

For soft water service:
• Open the inlet and outlet

valves

• Close the bypass valve

For bypass hard water:
• Close the inlet and outlet

valves

• Open the bypass valve

Salt hole
cover
removed

SALT
GOES HERE

Brinewell

INLET

Washer (2)

Copper tube, 3/4

(2)

Installation nut (2)

Bypass Valve
• Pull out for service
• Push in for bypass

NOTE: Threads on the bypass
valve are 1

male pipe. If 1

pipes are needed, do not use
the copper tubes and nuts
included. Buy 1

pipe thread

female adapter, and plumb
directly to 1

threads.

Adapters for this installation are not supplied with the softener.
To order these adapters, call GE Parts 800-626-2000. (Ask for Part # WS60X10006.)

Nut (2)

Copper
tube,
3/4

(2)

Washer (2)

Installation adapter (2) (see above)

INLET

NOTE: Threads on the installation adapters are 1

male pipe. If 1

pipes are needed, do not use the

copper tubes and nuts included. Buy 1

pipe thread

female adapter and plumb directly to 1

threads on

installation adapters.

CROSS-OVER

Use if water supply flows from

the left. Include single or

3-valve bypass.

Fig. 1

Fig. 2

Union (not supplied) (2)
