Service

When the water softening system is providing soft water, it is called “Service.” During service, hard water flows
from the house main water pipe into the water softening system. Inside the water softening system resin tank is a
bed made up of thousands of tiny, plastic resin beads. As hard water passes through the bed, each bead attracts
and holds the hard minerals. This is called ion-exchanging. It is much like a magnet attracting and holding
metals. Water without hard minerals (soft water) flows from the water softening system and to the house pipes.

After a period of time, the resin beads become coated with hard minerals and they have to be cleaned.
This cleaning is called regeneration, or recharge. Regeneration is started at 2:00 AM (factory setting) by the
water softening system control, and consists of five stages or cycles. These are FILL, BRINING, BRINE RINSE,
BACKWASH
and FAST RINSE.

About the water softener system.

12

Automatic Hard Water Bypass During Regeneration

For emergency needs, hard water is available to the
home during the regeneration cycles.

However, you should avoid using HOT water because
the water heater will fill with the hard water.

Fill

Salt dissolved in water is called brine. Brine is needed to clean the hard minerals from resin beads. To make the
brine, water flows into the salt storage area during the fill stage.

Brining

During brining, brine travels from the salt storage area into the resin tank. Brine is the cleaning agent needed
to remove hard minerals from the resin beads. The hard minerals and brine are discharged to the drain.

The nozzle and venturi create a suction to move the brine, maintaining a very slow rate to get the best resin
cleaning with the least salt.

Brine Rinse

After a pre-measured amount of brine is used, the brine valve closes. Water continues to flow in the same path
as during brining, except for the discontinued brine flow. Hard minerals and brine flush from the resin tank to
the drain

.

Backwash

During backwash, water travels up through the resin tank at a fast flow rate, flushing accumulated iron, dirt,
and sediments from the resin bed and to drain.

Fast Rinse

Backwash is followed by a fast flow of water down through the resin tank. The fast flow flushes brine from the
bottom of tank, and packs the resin bed.

After fast rinse, the water softening system returns to soft water service.
