Mercury 1200 and 1500P Encoder Systems
with Rotary scale
Mounting screws
& flat washers
S
Syysstte
em
m V
Viie
ew
w
Shown with rotary scale
E
Exxp
pa
an
nd
de
ed
d V
Viie
ew
w
Rotary scale
Mounting hole (2)
Index mark
Top reflective rotary scale
Rotary glass scale
Page 3
Typical user-supplied
sensor mounting bracket
located here
Sensor head
