CAUTION!

When installing the Power Distribution Center

cover, it is important to ensure the cover is prop-
erly positioned and fully latched. Failure to do so
may allow water to get into the Power Distribu-
tion Center, and possibly result in a electrical
system failure.

When replacing a blown fuse, it is important to

use only a fuse having the correct amperage
rating. The use of a fuse with a rating other than
indicated may result in a dangerous electrical
system overload. If a properly rated fuse contin-
ues to blow, it indicates a problem in the circuit
that must be corrected.

Front Power Distribution Center Fuses

Cavity

Fuse

Circuits

1

20 Amp
Yellow

Left High Beam Headlight

2

20 Amp
Yellow

Right High Beam Headlight

3

15 Amp
Dk. Blue

Adjustable Pedal

4

20 Amp
Yellow

Horn

5

25 Amp
Clear

Headlamp Washer — If
Equipped

6

15 Amp
Dk. Blue

Front Control Module (FCM)

7

20 Amp
Yellow

Fog Lamp

8

15 Amp
Dk. Blue

Park Lamp

9

15 Amp
Dk. Blue

Non ABS Brakes

10

5 Amp
Orange

Starter

MAINTAINING YOUR VEHICLE

291

7
