Dynex DX-PHD35 - Manual (Page 9)

Disconnecting the enclosure from your computer
9
DX-PHD35
To add file extensions to one of the preset file selection categories:
1 Select the file category you would like to customize. The choices
are Email, Financial, Music, Photos, Productivity, and
Video & Recorded TV.
2 Enter the file extension you would like to add into the Extension
text box.
3 Click Add. The file extension is added to the list box on the right.
4 Continue adding file extensions one at a time until you are
finished.
5 Click OK.
Using one-touch backup
To use one-touch backup if you have set up a backup project:
• Press the One-Touch button on the HDD enclosure. The backup
process begins.
To use one-touch backup if you have NOT set up a backup project:
1 Press the One-Touch button on the HDD enclosure. The Roxio
BackOnTrack software opens with the Backup Files page
displayed.
2 Follow the on-screen instructions to set up a backup project.
3 After a backup project is set up, push the One-Touch button to
backup your data.
4 To modify One-Touch backups in the future, follow the
instructions for setting up backup projects.
Restoring files
The Restore Files project restores individual files and folders that you
have protected using the Backup Files project. With Restore Files, you
select a backup, search for the files or folder you would like to restore,
and then click the action button. The files are restored to the location
you choose.
To restore a file:
1 Click the Backup Files tab in the project list. A list of projects is
displayed.
2 Click the Restore Files project. The project window opens.
3 If the backup file was saved on a disc, insert the disc into a
compatible disc drive.
4 Click Browse at the top of the Selective Restore project window. A
dialog box opens.
5 Use the dialog box to navigate to the backup file that contains
the files you would like to restore. After you have found the
backup file, click it, then click OK. The content of the backup file
appears as a directory tree in the project window.
6 Select the files and folders you would like to restore using one of
the following methods:
• Navigate through the directory tree in the project window.
When you find a file or folder you want to restore, select it by
clicking on its name.
• Type all or part of a file or folder name into the Search box to
the right of the Browse button. Click Search. The search
results are displayed in the project window. If the file you
want to restore appears in the search results, select it by
clicking once on its name. If the file does not appear in the
search results, try using different search terms or looking in a
different backup file.
7 Choose Browse from the Destination Selection menu and select
the location where your restored files will be saved.
8 Click the action button to begin restoring your files.
Restore files tips
• Restore Files can be used to restore as many files or folders as you
wish.
• Restore Files will not overwrite a file without getting your
permission.
• Backup files created with the Backup Files project can be
recognized by their .rfc file name extension. If you double-click
an .rfc file, the project launcher opens with the Backup Files
project displayed. To restore files, switch to the Restore Files
project.
• The Restore Files search box does not support wildcard
expressions.
• System files cannot be restored to their original location if they
are in use by your computer's operating system.
Disconnecting the enclosure
from your computer
You can disconnect the enclosure at any time while the computer is
turned off. If, however, you want to disconnect it while the computer is
on, make sure that you do it correctly.
To disconnect the enclosure while Windows is running:
Note: If a drive window is open or the hard drive enclosure is active, close
any associated windows before trying to remove the enclosure.
1 Right-click the Safely Remove Hardware icon (located near
the clock on the taskbar).
2 Click the device you want to unplug, then click STOP.
3 When Windows notifies you that it is safe to do so, unplug the
enclosure from your computer.
To disconnect the enclosure while Mac OS X is running:
1 Drag the USB icon into the TRASH.
2 Unplug the enclosure.
Uninstalling the backup software
To uninstall the backup software in Windows:
1 Open the Control Panel.
2 Click the Add or Remove Programs tab (Windows XP) or
Uninstall a Program (Windows Vista and 7).
3 Click Roxio BackOnTrack, then click Change/Remove
(Windows XP) or Uninstall (Windows Vista and Windows 7).
4 Follow the on-screen instructions to remove the software
completely from your computer.
5 After the software is uninstalled, restart your computer if
prompted.
