Chapter 6 Memory Buffer Allocation 6-3
DWORD dwBufferType; /* Data Buffer type. */
DWORD dwBufferSize; /* Size of each buffer in bytes. */
DWORD dwBufferWrite; /* Number of data samples in the buffer. */
DWORD dwBufferRead; /* Number of data samples obtained from the buffer. */
DWORD dwTrigPoint; /* App linear address of the trigger point. */
DWORD dwTrigPointStart; /* App linear starting address of the */
/* pre-trigger data. */
DWORD dwDoneFlag; /* Buffer complete flag */
DWORD dwStatusFlags; /* Current status */
long lErrorFlags; /* Buffer errors */
DWORD
dwBuffNum; /* Buffer number ID */
}DATABUFFSTAT;
typedef DATABUFFSTAT FAR * LPDATABUFFSTATUS;
Visual Basic for Windows adlib.bas file
Type DATABUFFSTATUS
lBufferType As Long ' Data Buffer type.
lBufferSize As Long ' Size of each buffer in bytes.
lBufferWrite As Long ' Number of data samples in the buffer.
lBufferRead As Long ' Number of data samples obtained from the buffer.
lTrigPoint As Long ' App buffer position number of the trigger point.
lTrigPointStart As Long ' App buffer position number of the pre-trigger data.
lDoneFlag As Long ' Buffer complete flag
lStatusFlags As Long ' Current status
lErrorFlags As Long ' Buffer errors
lBuffNum As Long ' Buffer number ID
End Type
6.4 BUFFER NOTIFICATIONS
6.4.1 C\C++
The user application has three choices of obtaining a pointer to a buffer that has been completed
(BUFFER_DONE).
1. The first method involves calling the ADLIB function AL_GetDoneBuffPtr(LHLD), which will return
a pointer to the next completed buffer when available, otherwise this function returns NULL.
2. The second method uses Windows Post-message handler routine installed by the user application.
Each time a buffer is completed the user routine will be called, passing a pointer to the buffer in the
1Param parameter. See example program adlai01.
Example:
