12 106746
PORTABLE GASOLINE GENERATORS

Choke Lever (Open Position)
Figure 19 - Choke Lever Opened (Model
PGH7500IE Shown)
HONDA
OFF
ON
START
ENGINE SW
CIRCUIT
BREAKER
ON/push OFF
Figure 18 - Engine Switch
Engine
Switch
Note: If oil level is too low, oil alert system
will keep engine from starting (see Oil Alert
System, page 6). Make sure oil level is full
before starting. See Engine Oil, page 7.
Before starting the engine, disconnect all
electric loads from generator.
STARTING
IMPORTANT: The engine speed is preset.
The throttle is locked in preset position. Do
not adjust throttle. Preset position lets en-
gine run at 3600 RPM under load. The
engine must maintain 3600 RPM for gen-
erator to create correct voltage. Running
engine at lower speeds will damage genera-
tor and powered items.
IMPORTANT: Never start generator with
electrical loads connected. Start engine be-
fore adding electrical loads.
1. Make sure gasoline tank is full. See
Fuel, page 7, for fuel information.
2. Move fuel valve lever to the ON posi-
tion (see Figure 16).
3. Move choke lever fully to the left (see
Figure 16) or pull choke button out
(Model PGH11000IE only, see Figure
17). This closes the choke.
Note: You may not need to close choke
if engine is warm or air temperature is
high.
Fuel Valve Lever (ON Position)
Choke Lever (Closed Position)
Figure 16 - Fuel Valve Lever On, Choke
Lever Closed (Model PGH7500IE Shown)
Figure 17 - Choke Button Closed (Model
PGH11000IE Only)
Choke Button
Pulled Out
(Closed Position) 4. Start the engine.
A. Recoil Starter
Turn engine switch to the ON position
(see Figure 18). Remove slack from
starter rope by lightly pulling starter
grip. Next, pull starter rope briskly.
IMPORTANT: Do not let starter grip
snap back against engine. Return it gen-
tly. This will prevent damage to starter.
Note: If engine does not start, check
the oil in the crankcase. Add oil as nec-
essary. Be sure engine is on a level sur-
face. See Oil Alert System, page 6.
B. Electric Starter
Turn the engine switch to the START
position (see Figure 18). Hold it there
until engine starts. When engine starts,
let switch return to the ON position.
IMPORTANT: Do not use electric
starter more than five seconds. Starter
motor damage may occur. If engine
fails to start, release the switch and wait
ten seconds. After ten seconds, try start-
ing again.
Note : If engine does not start, check
the oil in the crankcase. Add oil as nec-
essary. Be sure engine is on a level sur-
face. See Oil Alert System, page 6.
5. As engine warms up, slowly move
choke lever fully to the right (see Fig-
ure 19). This opens the choke. On
Model PGH11000IE, the choke will au-
tomatically open.
PRESTART
Operate generator on a firm, dry, and clean
surface. The surface must be level. Protect
generator from heavy dust, sand, dirt, rain,
or snow. Do not locate generator near stand-
ing water and snow. Make sure area is well
vented.
OPERATION
Continued
WARNING: Only responsible
adults should use generator.
Never let anyone operate genera-
tor without proper instructions.
