- 30 -

IDEAL 4815 • IDEAL 4850

2.

1.

2.

A

1.

3.

B

Lightly tighten 2 of the 5 blade screws with

washers (1.). Remove the blade changing

tool (2.). Lightly tighten the remaining blade

screws with washers (3.).

Lightly screw in the right blade screw with the

washer (A) when the blade is lowered.

Remove all tools and distribute paper along

the entire cutting length (1.).

Turn main switch to position "I" (2.).

•

Blade and cutting stick replacement

•
