23 104307
OWNER’S MANUAL
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 26 of this manual. PARTS LIST
CGD3924PR
KEY
NO.
PART NUMBER DESCRIPTION QTY.
1 103008-01 Back Log (#1) 1
2 103009-01 Middle Log (#2) 1
3 103010-01 Front Log (#3) 1
4 103011-01 Crossover Log (#4) 1
5 103778-01 ODS Pilot (LP) 1
6 098249-01 ODS Nut 2
7 103342-02 Burner Outlet Tube 1
8 098264-02 Male Connector 1
9 102843-01 Bur ner Clip 1
10 099056-17 Burner Orifice Injector 1
11 102966-01 Upper Bracket 1
12 102772-01 Burner 1
13 099387-09 Pilot Tube 1
14 103781-02 Gas Control Valve 1
15 103345-01 Lower Bracket 1
16 M11084-38 Screw, #8 x .38 7
17 102775-06CK Painted Base Assembly 1
18 098271-07 Ignitor Cable 1
19 102445-01 Piezo Ignitor 1
20 103823-01 Remote Set (Incl. Transmitter) 1
21 104099-01 Heat Shield 1
22 098304-01 Screw 2
23 103784-02 Flame Adjustment Knob 1
24 103784-01 Off-Pilot-On Knob 1
25 M12461-26 Screw, Hex Slt Wsr 10-32 x .38 4
PARTS AVAILABLE — NOT SHOWN
100563-01 Warning Plate 1
103877-01 Lighting Instructions Plate 1
100565-01 Warning Plate Fastener 1
100639-01 Caution Decal 1
101137-02 Hardware Kit 1
104310-02 Information Video 1
GA6060 Lava Rock 1
