COMMON FEATURES
Electrical Installation
To make electrical connections to your SC6000 controller proceed as follows:
1. Connect the SC6000 controller to the PWO by means of the appropriate accessory cables for your
application.
2. Provide correct and complete system cabling through the PWO according to the signals (Lonworks,
encoder P.S., etc.) necessary for the layout of your application. Refer to the PWO Installation Manual for
details.
Software Installation
To install Genius™, proceed as follows:
1) Turn on the PC that will be used for configuration (Windows 98, NT or XP);
2) Insert the Genius™ CD-ROM;
3) Wait for the CD to autorun and follow the installation procedure.
4) See the Reference Manual for Software Configuration procedures.
Accessories
The following accessories are used to build up a reading station based on SC6000 (the scanner-related
accessories are not included):
Name Description Part Number
CAB-SC6003 25p cable SC6000 to PWO, 3 m
(for Power/Net & Extended I/O connections) 93A051293
CAB-SC6103 9p cable SC6000 to PWO, 3 m
(for Main and Modem connections) 93A051294
CAB-PWO 03 17p cable PWO to PWO, 3 m
(for redundancy) 93A051295
PWO-480 Power&Connect system, 480W 93ACC1767
Modem INSYS Modem 56K 93A051294
