8
ENGLISH
!3 Pitch slider
• Use this to adjust the playing speed.
• The playing speed decreases when moved
upwards and increases when moved downwards.
!4 PITCH/KEY, RANGE button
• With this button you can select PITCH and KEY
ADJUST mode. Mode changes Pitch on, Key
Adjust on and both off cyclically. Green LED
indicates in Pitch mode and Orange indicator in
Key Adjust mode. No LED indicates OFF mode.
• RANGE:
Push this button for more than 1 sec to select
the pitch range. The pitch range can be
selected with the TRACK SELECT knob from
±4, 10, *16, 24, 50 or 100%. (*Max pitch for
MP3)
!5 TIME, TOTAL button
• Push this to switch the time display between
the elapsed time or remaining time per track or
per disc.
• When this button is pushed for more 1 second,
you can display the total time. (4 way, audio,
CD only)
!6 Display
• See page 9.
!7 Shuttle ring (outer ring)
• This control is used to select the scanning
direction and speed.
The CD is scanned in the forward direction
when the shuttle ring is turned clockwise from
the center position. To scan backwards, the
shuttle ring is turned counterclockwise.
• The scanning speed increases as the wheel is
turned further.
!8 Disc holder OPEN/CLOSE button
• Push this button to open and close the disc
holder.
• The disc holder will not open during playback.
Stop playback before pushing this button.
3 PART NAMES AND FUNCTIONS (Refer to page 3.)
(1) DN-D4500 Front panel
q POWER button ( ¢ ON £ OFF)
• Push this button to turn the power on.
w POWER indicator
• This lights when the power is on.
e Disc holder
• Place discs in this holder.
• Push the disc holder OPEN/CLOSE button to
open and close the disc holder.
r Disc holder LED
• This flashes while the disc holder is opening
and closing.
• The LED lights when the disc holder is open
and serves as the disc holder illumination.
t Disc holder OPEN/CLOSE button
• Push this button to open and close the disc
holder.
• The disc holder will not open during playback.
Stop playback before pushing this button.
NOTE:
• Be sure to close the disc holders before
turning off the power.
CAUTION:
• Do not place foreign objects in the disc
holders. Doing so could damage the player.
• Do not push the disc tray in manually when
the power is off, as this may result in
malfunction and damage the player.
(2) RC-D45 Front panel
CAUTION:
• Note that there are many buttons working two
different functions selected by short time
pushing or long pushing (1second or more). The
mark indicates short time push function and
mark indicates long time push function.
o TRACK SELECT/MP3 SEARCH
MODE knob
• TRACK:
Turn this knob to select the first or next track to
be played.
Turn the knob clockwise by one click to move
one track forward, counterclockwise by one
click to move one track backward.
When the knob is turned while pressing it
down, one click corresponds to advancing 10
tracks at a time.
In the Preset and Memo mode, use this knob
to set and enter Preset and Memo settings.
• MP3 SEARCH MODE:MP3 DISC only.
When pushing this knob down for more than 1
second, the MP3 file search selection mode is
selected.
!0 CUE button
• Pushing the CUE button during play provides a
return to the position at which play was
started. Alternately pushing the PLAY/PAUSE
button and the CUE button allows the CD to be
played from the same position any number of
times.
• The CUE button lit, when the standby mode is
set.
• In CUE mode, by pushing the CUE button
makes a Stutter sound from the CUE point. This
is called Stutter play for added performance.
(Stutter)
!1 PLAY/PAUSE button ( 13 )
• Use this button to start playback.
• Push once to start playback, once again to set
the pause mode, and once more to resume
playback.
• When the Brake mode is ON, push the
Play/Pause to activate the Brake sound.
!2 PITCH BEND +/– button
• The playing speed increases/decreases while
these buttons are held down.
• When either button is released, the playing
speed returns to the previous speed.
y Jog wheel (inner wheel)
• In the pause, CUE or Frame repeat mode, turn
this wheel during for search operation to find
the CUE point in units of frames.
• In the Playback mode, turn this wheel to
temporarily pitch bend the playing speed.
u Continue/Single button
(
CONT./SINGLE, RELAY)
• CONT./SINGLE:
Short pushing play ending mode between
CONT. (continue: play more tracks) and
SINGLE (stop playing and ReCUE’s back to
your set point).
• SINGLE PLAY LOCK:
SINGLE PLAY LOCK can be selected by
PRESET(10). At this time , if this button is
pushed, it will be selected. When SINGLE
PLAY LOCK is selected, track selection during
playback is disabled. This prevents playback
from stopping when the Track Select Knob is
turned accidentally during playback. Play
ending mode is the same as single.
• RELAY:
When this button is pushed for more than 1 sec,
you can turn on and off RELAY PLAY mode.
i BRAKE button
When this button is pushed you can turn the
Brake mode on and off.
