XDVD9101 OPERATION
10
Control Functions - Monitor Closed
When the monitor is closed, press DISP to toggle display between
information available for the current mode such as clock, frequency, track or
chapter information.
Additional LCD for system information while monitor is closed.
Press OPEN to open or close the monitor. Be careful not to not touch
or obstruct the monitor movement during the open/close sequence, or
permanent damage could occur.
Connect external devices or the included cable for an iPod device to this
3.5mm auxiliary audio/video input.
Insert USB flash drive to play MP3, WMA or JPEG files. Connect included
cable for an iPod device to control and charge an iPod device.
To resolve abnormal operation or if the unit is inoperable, press the
RESET button located to the left of the USB input on the front panel.
The unit
will reset the main processor to the default settings.
Note: Use the tip of a pen to access the reset button. To restore the factory
default settings, refer to page 19.
Press to select the next channel/chapter/track for playback.
Press and hold to manual tune up or fast forward.
In disc mode, press once for PAUSE, and "PAUSE" will appear in the display.
Press again to resume PLAY.
Press to select the previous channel/chapter/track for playback.
Press and hold to manual tune down or fast reverse.
Red = Disc inserted, Blue = No disc.
Point the remote control towards the infrared sensor to control various
functions of the unit.
Press BAND to increment from FM1, FM2, ] AM. While in disc mode, press
BAND momentarily to stop disc play.
Press MODE to select between Tuner, Disc (which includes DVD and CD
playback), operation of iPod, USB, Auxiliary 1 and Auxiliary 2 inputs. Each
time the MODE button is pressed the next mode is chosen. Modes of
operation are indicated on the OSD or the secondary LCD. Optional iPod
device or USB flash drive must be connected/inserted to appear in the MODE
selection string.
Press MUTE to silence audio output. "MUTE" will flash in the secondary
display. Press MUTE again to restore audio at previous volume level. Press
and hold MUTE to toggle the Loudness function On or Off.
Press once to eject disc.
Display
Secondary LCD
Open Monitor
3.5mm A/V Input
USB Input
Reset
Channel/Chapter/Track Up
Fast Forward
Play/Pause
Channel/Chapter/Track Down
Fast Reverse
Disc-in Indicator
Infrared Sensor
Band
Mode
Mute
Eject
