www.desatech.com 111924-01D 31
PARTS LIST
bURNER ASSEMbLY MODELS (V)k36EN, (V)k36ENH, (V)k36EP AND (V)k36EPH
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 27 of this manual.
kEY
NO. PART NO.
DESCRIPtION qtY.
1 111957-01 Pan Assembly Burner 1
2 111311-01 Grate Base 1
3 111312-01 Burner Base Bottom 1
4 26808 Valve Bracket 1
5 11107 Screw, #10-32 x 1/4 PPH Zinc 4
6 104506-23 Burner Orifice (Natural Gas) 1
104506-17 Burner Orifice (Propane/LP Bas) 1
7 11102 Screw, #8-32 x 3/8 PPH Zinc 2
8 108866-01 Pilot (Natural Gas) 1
108866-02 Pilot (Propane/LP Gas) 1
9 111316-01 Pilot Bracket 1
10 111913-01 Burner Base Gasket 1
11 111310-01 Firebox Bottom 1
12 11165 Screw, #10 x 5/8 HWH Zinc 12
13 26287 Switch Bracket 1
14 14500 Brass Fitting 1
15 111912-01 Tubing Assembly 1
16 14569 Electronic Elec. Valve (Natural Gas) 1
14570 Electronic Elec. Valve (Propane/LP Gas) 1
17 14253 Flex Gas Line 1
18 11186 Screw, #8-32 x 1 Zinc 2
19 110286-01 Ignition Module, Synetek 1
20 11147 Screw, #10-24 x 1/2 PPH MS Blk 2
21 14129 Transformer 24V Class 1
22 17223 Magnet 2
23 11201 Nut, 8-32 Hex Zinc 4
24 23416 Elect. Components Board 1
25 14120 Spade 1/4 Female Connector 4
26 14134 Wire, 18 GA Black 5
27 14126 Wire, 16 GA TFFN/MTW 1
28 14115 Spade toungu connector 1
29 14149 Spade, 1/4 F R/Angle Connector 4
30 108863-01 24" Supply Connector Pug 1
