www.desatech.com 111924-01D 29
PARTS LIST
MODELS (V)k36EN, (V)k36ENH, (V)k36EP AND (V)k36EPH
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions listed under Replacement Parts
on page 27 of this manual.
k36EN
k36EP
Vk36EN
Vk36EP
k36ENH
k36EPH Vk36ENH
Vk36EPH DESCRIPtION
qtY.
110989-02 110989-01 111215-02 111215-01 Left Refractory Brick Panel 1
110991-02 110991-01 111217-02 111217-01 Rear Refractory Brick Panel 1
110990-02 110990-01 111216-02 111216-01 Right Refractory Brick Panel 1
kEY
NO. PART NO. DESCRIPtION qtY.
1 ** Firebox Assembly 1
2 ** Face Weldment 1
3 108010-01 Door Assembly 1
108010-02 Door Assembly (V Models Only) 1
4 108011-01 Top Louver Assembly 1
5 108011-02 Bottom Louver Assembly 1
6 ** Fireplace Top 1
7 ** Fireplace Top Insulation 1
8 ** Fireplace Surround 1
9 109082-01 Heat Shield 1
10 111958-01 Log Set 2
10-1 111933-01 Left Base Log 1
10-2 111932-01 Right Base Log 1
10-3 111961-01 Left Front Log 1
10-4 111960-01 Right Front Log 1
10-5 111926-01 Right Rear Log 1
10-6 111929-01 Middle Crossover Log 1
10-7 111959-01 Left Rear Log 1
10-8 111930-01 Left Crossover Log 1
10-9 111962-01 Right Crossover Log 1
11 see below Left Refractory Brick Panel 1
12 see below Rear Refractory Brick Panel 1
13 see below Right Refractory Brick Panel 1
14 108719-01 Screen Rod 1
15 12105 Screen 2
16 11418 Push-On Nut 2
17 14123 Strain Relief 1
18 21171 Gas Knock-Out Cover 2
19 24353 Handy Box Assembly 1
20 24460 Gas Conduit Assembly 1
21 111956-01 Burner Assembly (Natural Gas) (See pages 30 and 31) 1
111956-02 Burner Assembly (Propane/LP Gas)
PARTS AVAILAbLE - NOT SHOWN
25487 Lava Rock/Bag Assy 1
27253 Notice Label 1
55240 Vent Label 1
** Not a field replaceable part.
