PARTS LIST
FIREPLACE MODELS
EFS33NRB, VSGF33NRB, EFS33PRB AND VSGF33PRB
This list contains replaceable parts used in your fireplace. When ordering parts, follow the instructions
listed under Replacement Parts on page 27 of this manual.
KEY
NO. PART NUMBER
DESCRIPTION
QTY.
1
101357-01
Top Outer Casing
1
2
103207-01
Outer Casing
1
3
102758-02CK
Right Front Side
1
4
102759-02CK
Left Front Side
1
5
098304-01
Phillips Pan Head Screw, #10
17
6
101351-01CK
Top Front
1
7
102455-18
Louver
2
8
101353-01CK
Middle Front Rail
1
9
101712-02
Firebox Hood
1
10
101348-01
Firebox Support
2
11
099230-01
Shoulder Screw
4
12
101872-03
Firebox Top
1
13
**
Outer Base
1
14
**
Firebox Wrapper
1
15
101514-01
Cover
1
16
M11084-26
Hex Screw, #10
57
17
098304-02
Phillips Pan Head Screw, #6-20x.38
4
18
101727-03
Screen Assembly
1
PARTS AVAILABLE — NOT SHOWN
100639-01
Caution Decal
1
103590-01
Decal Strip
1
104313-01
Hinge, Pin
1
104313-02
Hinge, Pin
1
M10908-2
Screw, Slotted Hex Head Tapping
4
**Not a field replaceable part.
