ELECTRONIC MONITOR
(on some models)
5
➀
Flashes when either door is open.
➁
When lit, the Door Alarm beeper is set to sound after either door
has been open 30 seconds.
➂
Lights up when freezer food-keeping temperature is above normal.
➃
Lights up to indicate that no failure has been detected by the
diagnostic system.
➄
Flashing diagnostic codes.
Check your frozen food. Has any of it started to thaw?
A package may be holding the freezer compartment door
open. Don’t open the door more often than absolutely
necessary while this code is displayed. Touching the
pad after the freezer compartment temperature has
returned to normal will erase the code.
Power to the refrigerator has been interrupted for
more than two seconds. Check the condition of food in
both the fresh food and freezer compartments. Touch the
pad to erase code.
There is no fault with the refrigerator when the PF
code flashes.
Check the icemaker. Ice clumps in the storage bin may
have stalled the icemaker. Follow corrective measures
described in the Problem Solver section. If water supply
to the icemaker is not connected or not turned on, make
sure manual icemaker switch is in the
(up) position.
This code stops flashing when problem is corrected
or the
pad is touched.
Something is wrong with the defrost system—keep
doors closed to retain cold and call for service. The
code flashes until problem is corrected.
➅
Reviews the four coded functions and allows you to erase codes
from the display.
➆
chilled water, ice cubes or crushed ice.
4 1 3 5 6
2 7 7
When Your Refrigerator Is First Plugged In
All panel lights come on for five seconds, a beep sounds, and lights go
off except as follows:
• PF flashes in the display. Touch this pad to erase it.
• This pad glows.
• The Warm Temperature light glows if the freezer
compartment temperature is higher than normal.
It goes off when proper food-keeping temperature
is reached.
• The Door Alarm beeper is activated and the Door
Alarm pad glows.
• The Crushed Ice pad glows.
• This pad flashes if either door is open, goes out
when doors are shut.
• The night light in the ice and water dispenser is off.
(continued next page)
