CARE AND CLEANING
(continued)
Light Bulb Replacement
14
Fresh Food Compartment—Upper Light
1. Unplug the refrigerator.
2. For easiest reassembly move the
knobs to their lowest setting, then
pull off the knobs
3. Pull the light shield down and
forward, then rotate the top up and
off. After replacing with same size
bulb, reinstall light shield and set
the knobs to the position that they
were at before; or set both knobs
at “5”. If you cannot locate the
correct bulb, see your dealer.
4. Plug the refrigerator back in.
Fresh Food Compartment—Lower Light (on some models)
This light is located either behind the top drawer or right above the top
drawer (depending on your model).
1. Unplug the refrigerator.
2. If the light is behind the top drawer you will need to remove the
drawer and the shelf above it. To remove the drawer see the Drawer
Removal section in Care and Cleaning.
• To remove the shelf first
remove any food on the shelf.
Then tilt the shelf up at the front
and lift it up and out of the
tracks.
3. Grasp the bottom of the light
shield and pull it forward and up.
4. After replacing with the same size
bulb, replace the shield. If you
cannot locate the correct bulb, see
your dealer.
5. If the light was behind the top drawer, you will need to replace the
drawer and the shelf above it.
• To replace the shelf, raise the shelf front slightly and place the top
hooks in the lowest large track slots. Then lower the front of the
shelf until it is level.
6. Plug the refrigerator back in.
Refreshment Center (on some models)
1. Unplug the refrigerator.
2. Open fresh food compartment door,
remove top bin and raise Refreshment
Center inner door.
3. Press sides of flexible light shield to
release locking tabs and allow the
shield to swing down.
4. Unscrew burned-out bulb and replace it with appliance light bulb of
same wattage. If you cannot locate the correct bulb, see your dealer.
5. Place rear tab of light shield into door and rotate shield up until tabs
lock into slots above.
6. Plug refrigerator back in.
Freezer Compartment with a Dispenser
1. Unplug the refrigerator and
remove the ice bin.
2. Remove the screw holding the light
shield in place.
3. Shift the shield to the left to free the
tabs, then lower it.
4. After replacing with same size bulb,
hook the shield in place and replace
the screw. If you cannot locate the
correct bulb, see your dealer.
5. Plug the refrigerator back in.
Freezer Compartment with no Dispenser
1. Unplug the refrigerator and
remove the top shelf.
2. Remove the two screws holding
the light shield in place.
3. Pull the light shield toward you
to reach the bulb.
4. After replacing with same size
bulb, hook the shield in place
and replace the screw. If you
cannot locate the correct bulb,
see your dealer.
5. Plug the refrigerator back in.
Screw
Screws
