Base Station Indications
40 Gryphon™ I GM4100
Base Station Indications
INDICATION LEDS
Power-up Complete Yellow LED on
Reader Disabled by the HOST or the com-
munication with HOST is not established
Yellow LED blinking ~1Hz
Data/labels are transmitted to the HOST
Yellow LEDs turned off for
100mSec
Programming Mode Yellow LED blinks quickly
Configuration alignment with the HH is in
progress
Red LED blinks quickly
Battery charger in progress Red LED on
Battery charger complete Green LED on
Battery charger error
Green LED and Red LEDs blink
alternatively ~1Hz
No HH is placed on the cradle Red and Green LEDs off
