LED and Beeper Indications

Gryphon™ I GM4100

Reader
Disabled

The reader has
been disabled by
the host.

The LED blinks
continuously

N/A

Green Spot is on
continuously

While in Stand
Mode or Trigger
Stand Mode the
green spot shall
be on while in
stand watch
state.

N/A

Green Spot

flashes momen-
tarily

Upon successful
read of a label,
the software shall
turn the green
spot on for the
time specified by
the configured
value.

N/A

Programming Mode - The following indications ONLY occur when the reader is
in Programming Mode.

Label Program-
ming Mode
Entry

A valid program-
ming label has
been scanned.

LED blinks con-

tinuously

Reader sounds

four low fre-

quency beeps.

Label Program-
ming Mode
Rejection of
Label

A label has been
rejected.

N/A

Reader sounds
three times at
lowest fre-
quency and cur-
rent volume.

Label Program-
ming Mode
Acceptance of
Partial Label

In cases where
multiple labels
must be scanned
to program one
feature, this indi-
cation acknowl-
edges each
portion as it is
successfully
scanned.

N/A

Reader sounds

one short beep at

highest fre-

quency and cur-

rent volume.

INDICATION

DESCRIPTION

LED

BEEPER
