POWERSCAN ® D8330/M8300
2
2 INSTALLATION
CAUTION
Connections should always be made with power OFF!
2.1 POWERSCAN ® D8330 INTERFACE CABLE CONNECTIONS
The PowerScan
® D8330 reader incorporates a multi-standard interface, which can be
connected to a Host by plugging the correct interface cable into the connector and
closing the cable cover.
A. Rubber gasket
B. Plastic boot
C. Cable spacer
D. Cover
E. Strain relief
