JLCooper Gangway16 User Manual
Page 10
10
Pin GPI
1-8 GPI
9-16
1
Input 4
Input 12
2
Input 3
Input 11
3
Input 2
Input 10
4
Input 1
Input 9
5
Ground Ground
6
Ground Ground
7
+ 5 Volts
+ 5 Volts
8
Ground Ground
9
Ground Ground
10
Output 8
Output 16
11
Output 5
Output 13
12
Output 3
Output 11
13
Output 1
Output 9
14
Input 5
Input 13
15
Input 6
Input 14
16
Input 7
Input 15
17
Input 8
Input 16
18
Ground Ground
19
Ground Ground
20
Ground Ground
21
Ground Ground
22
Output 7
Output 15
23
Output 6
Output 14
24
Output 4
Output 12
25
Output 2
Output 10
GPI Pinout
Power
The Gangway16 requires a 9-12 volt DC power supply capable of
delivering at the minimum, 0.5 amps. The unit comes with a
power supply (JLCooper part number PSDC117). If you need a
power supply specific to your location, please contact your local
distributor or JLCooper Electronics.
Warning: Using a power supply other than, the unit specified could
result in damage to the Gangway16 and/or other equipment, which is
not covered by the JLCooper Factory Warranty.
