Dimensions (in.) – Ducane RHP13 User Manual
Page 6
Residential Packaged Unit Heat Pump
- Page 6 -
Dimensions (in.)
Model No.
A
B
C
D
E
F
RHP13-24
32-1/2
46-1/2
46-1/2
45-5/8
45-5/8
17-1/2
RHP13-30
RHP13-36
RHP13-42
34-1/2
55-1/2
50-1/2
54-5/8
49-5/8
21-1/2
RHP13-48
RHP13-60
Model No.
G
H
J
K
L
RHP13-24
11-1/2
5-1/2
1-5/8
4
4
RHP13-30
RHP13-36
RHP13-42
12
5-1/2
1-5/8
6-1/4
5-5/8
RHP13-48
RHP13-60
Model No.
M
N
P
Q
R
RHP13-24
1-3/4
15-5/8
27-3/4
24-7/8
9-3/4
RHP13-30
RHP13-36
RHP13-42
2-3/8
17-1/8
29-3/4
26-7/8
15-1/2
RHP13-48
RHP13-60
Elec. Heat
Power Entry
