Heat Strip Electrical
Model No.
Heater
Model
Unit
Supply
Single Phase
Heater
kW
Minimum
Circuit
Ampacity
1
Maximum
Fuse / HACR
Brkr. 2
1
Minimum
Circuit
Ampacity
2
Maximum
Fuse / HACR
Brkr.
2
RHP13A24P
RHP13A30P
RHP13A36P
AHSA05A
240 5.0 31.2 35 ---- ---
208 3.7 27.8 30 ---- ---
AHSA07A
240 7.0 41.7 50 ---- ---
208 5..3 36.8 40 ---- ---
AHSA010A
240 10.0 57.3 60 ---- ---
208 7.5 50.3 60 ---- ---
AHSA015A
240 15.0 57.3 60 26 30
208 11.3 50.3 60 22.5 25
RHP13A42P
RHP13A48P
RHP13A60P
AHSA05A
240 5.0 33.3 35 ---- ---
208 3.7 29.9 30 ---- ---
AHSA07A
240 7.0 43.8 50 ---- ---
208 5..3 38.9 40 ---- ---
AHSA010A
240 10.0 59.4 60 ---- ---
208 7.5 52.4 60 ---- ---
AHSA015A
240 15.0 59.4 60 26 30
208 11.3 52.4 60 22.5 25
AHSA20A
240 20.0 59.4 60 52.1 60
208 15.0 52.4 60 45.1 50
Heat Strip Electric
Accessories
Description Where Used Kit Number
5 kW Electric Heater All Models AHSA05A-1
7 kW Electric Heater All Models AHSA07A-1
10 kW Electric Heater All Models AHSA10A-1
15 kW Electric Heater All Models AHSA15A-1
20 kW Electric Heater 42, 48 & 60 AHSA20A-1
Roof Curb 24, 30 & 36 ACURB161-1
Roof Curb 42, 48 & 60 ACURB163-1
Manual Fresh Air Damper 24, 30, 36 ADMPR145-1
Manual Fresh Air Damper 42, 48, 60 ADMPR166-1
Motorized Fresh Air Damper 24, 30, 36 ADMPR146-1
Motorized Fresh Air Damper 42, 48, 60 ADMPR167-1
Downflow Economizer 24, 30, 36 AECON825-1
Downflow Economizer 42, 48, 60 AECON826-1
Horizontal Economizer 24, 30, 36 AECON827-1
Horizontal Economizer 42, 48, 60 AECON828-1
Sound Ratings
Model No.
Sound
dBA
RHP13A24P 77
RHP13A30P 77
RHP13A36P 77
RHP13A42P 80
RHP13A48P 80
RHP13A60P 80
Field Provided 1"
Filter Dimensions
Small Base 2, 2.5, 3 Ton
24" width
28" height
Large Base 3.5, 4, 5 Ton
30" width
30" height
