Residential Packaged Unit Heat Pump Residential Packaged Unit Heat Pump
Blower Performance
Model
Blower
Tap
CFM @ ext. Static Pressure in inches wc without filter, dry coil
0.2 0.3 0.4 0.5 0.6 0.7 0.8
RHP13A24P
1 640 460 370 --- --- --- ---
2 830 800 760 710 640 600 570
3 950 910 880 840 800 750 700
4 900 870 830 800 730 690 640
5 1060 1030 980 960 930 910 860
RHP13A30P
1 650 550 490 430 --- --- ---
2 1030 1000 970 930 900 860 820
3 1150 1110 1080 1050 1010 980 960
4 1110 1070 1040 1000 970 950 920
5 1150 1110 1080 1050 1010 980 960
RHP13A36P
1 650 590 500 430 --- --- ---
2 1240 1200 1150 1100 1060 1020 980
3 1320 1260 1230 1200 1160 1120 1080
4 1240 1200 1150 1100 1060 1020 980
5 1320 1260 1230 1200 1160 1120 1080
RHP13A42P
1 780 690 610 540 --- --- ---
2 1450 1370 1280 1200 1120 1060 990
3 1650 1570 1510 1440 1360 1260 1160
4 1510 1430 1380 1290 1220 1150 1090
5 1650 1570 1510 1440 1360 1260 1160
RHP13A48P
1 860 760 690 640 --- --- ---
2 1650 1600 1550 1500 1440 1370 1290
3 1800 1750 1690 1630 1570 1470 1330
4 1650 1600 1550 1500 1440 1370 1290
5 1800 1750 1690 1630 1570 1470 1330
RHP13A60P
1 1000 900 800 750 --- --- ---
2 1820 1790 1730 1670 1630 1530 1380
3 1950 1910 1860 1800 1700 1560 1360
4 1820 1790 1730 1670 1630 1530 1380
5 1950 1910 1860 1800 1700 1560 1360
Subtract .10 Duct Static for Downflow CFM Taps 4 & 5 are used with Electric Heat. Refer to Heater Label on unit for
proper Heat Tap selection
Heating Performance Extended Ratings
Model
Outdoor Temp - DB/WB ºF
0/0 17/15 35/33 47/43 62/56
Btuh kW Btuh kW Btuh kW Btuh kW Btuh kW
RHP13A24P 10,100 1.71 13,000 1.73 15,400 1.71 21,600 1.80 26,200 1.87
RHP13A30P 10,700 2.03 16,000 2.04 21,100 2.14 27,000 2.26 32,700 2.33
RHP13A36P 15,900 2.53 20,200 2.58 24,900 2.66 33,600 2.82 40,200 2.93
RHP13A42P 20,000 2.92 23,200 3.10 27,800 3.24 39,000 3.36 46,800 3.50
RHP13A48P 23,900 3.57 26,800 3.74 29,300 3.73 44,000 3.91 52,900 4.08
RHP13A60P 25,200 4.30 34,000 4.34 41,200 4.32 54,000 4.78 64,800 5.03
