HD4070
Product Configuration Manual
SPECIFICATIONS
• Touch Screen Display Option – The HD4070 display is a touch screen interface, providing all system
control functions and plasma process information at a single location. The power supply may be ordered
with the display mounted in the front panel. Kits are also available for mounting the display remotely.
4070.23B
13
TORCH 1
NO PILOT ARC
STAINLESS STEEL
NEW
PROCES
NEXT
AUTO
MAN
THC
ARC
VOLT
ARC
VOLT
OVERRIDE VOLTS: 144.5 V
SET ARC VOLTS: 142.0 V
INLET GAS: H35 N2
CUTTING SPEED: 65 IPM
3/4 IN
200 AMPS
STANDOFF: 0.050 IN
++
_ _
CNC
TORCH 1
READY
STAINLESS STEEL
NEW
PROCESS
NEXT
AUTO
MAN
THC
OVERRIDE VOLTS: 144.5 V
SET ARC VOLTS: 142.0 V
INLET GAS: H35 N2
CUTTING SPEED: 65 IPM
3/4 IN
200 AMPS
STANDOFF: 0.050 IN
ARC
VOLT
++
ARC
VOLT
_ _
13
HELP
Display Touch Screen Option
Warning: The HD4070 system can only support one touch screen display, either local or remote. The
installation of two displays on one system may cause malfunctions or damage.
