Step 2i, Part descriptions, Hardware descriptions – Hoist Fitness CL-2103 User Manual
Page 22
F R A M E A S S E M B L Y
Step 2i
9 - 8.6 LBS. Aluminum Top Plate
26 - 11 Plate Selector Stem
Part Descriptions
BK - 7/16” x 3” Open Roll Pin
Hardware Descriptions
Slide the Plate Selector Stem up into the 8.6 LBS Aluminum Top
Plate and secure with a 7/16” x 3” Open Roll Pin.
bolts
Wrench tighten
.
FITNESS SYSTEMS
R
HOIST
A S S E M B LY
I N S T R U C T I O N S
Page - 21
2103 Assembly
