A S S E M B LY
I N S T R U C T I O N S
F R A M E A S S E M B L Y
Step 2h
20 - Cam Belt
23 - 1 5/8” x 2 1/16” lg. tube
24 - 3/4” x 2 1/16 CRS
Part Descriptions
F - 1/4” x 1” Button Head Screw
Q - 1/4” Lock Washer
Hardware Descriptions
Slide the Cam Belt into the top slot of 1 5/8” Dia. x 2 1/16” Lg. Dom.
(Fig. 1) Loop the end of the Cam Belt and feed it back up through the
slot, keeping the loop open (Fig. 2). Next, slide the 3/4” x 2 1/16 CRS
through the Cam belt and line up the holes, then secure to the 1 5/8” Dia.
X 2 1/16” lg. tube.(Fig. 3).
bolts Wrench tighten .
FITNESS SYSTEMS
R
HOIST
Page - 19 2103 Assembly
