Page 30: Page 29

background image

ITEM NO.

PART NUMBER

DESCRIPTION

QTY.

72

011-0407000

1/2"-13UNC X 3.50" HHB (WZ)

2

73

011-0407047

1/2"-13UNC X 4.00" HHB (WZ)

4

74

011-0107038

1/2"-13UNC X 4.25" HHB (WZ)

2

75

011-0107014

1/2"-13UNC X 5.00" HHB (WZ)

2

76

011-0307060

1/2"-13UNC X 6.00" HHB (WZ)

5

77

011-0107066

1/2"-13UNC X 7.50" HHB (WZ)

1

78

011-0311013

3/8-16UNC X .75" SQUARE HEAD (WZ)

1

79

012-0104008

3/8"-16 UNC THIN NYLOCK NUT (WZ)

9

80

012-0304011

1/2"-13 UNC THIN NYLOCK NUT (WZ)

22

81

021-0003093

DECAL MOVING PARTS 1.20" X 2.38" (HOR)

4

82

021-0003130

WARNING DECAL 3.00" X 8.50"

1

83

021-0003230

DECAL HOIST 1.63" X 5.93"

1

84

021-0003320

DECAL 800 LB. WEIGHT RATING (1.6250" X 1.6253")

1

85

021-0003341

DECAL PINCH POINT 1.07" X 2.13" (HORIZONTAL)

2

86

021-0003627

DECAL HOIST 2.12" X 7.75"

2

87

021-0003405

DECAL ROX

2

88

021-0003784

RPL-5405 STANDING CALF RAISE PLACARD

1

89

021-0003787

DECAL COMMERCIAL MAINTENANCE 3.00 X 8.50

1

90

021-0004022

DECAL 1-10 VERTICAL

1

91

021-0018022

DECAL HOISTFITNESS.COM LOGO

1

92

SERIAL # DECAL

DECAL HOIST SERIAL # 1.63" X 2.63"

1

93

013-0408003

1/2" INTERNAL LOCK WASHER (SS)

2

94

013-0402002

1/2" X 27mm SAE FLAT WASHER (SS)

2

PART LIST CONTINUED

RPL-5405 ASSEMBLY

OWNER'S MANUAL

PAGE 29

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
