ITEM NO.
PART NUMBER
DESCRIPTION
QTY.
1
022-01PD2110-A
SHOULDER PAD
2
2
026-01X0185
PULL-PIN ASSEMBLY
1
3
026-01X3294
REAR UPRIGHT LEFT ASSEMBLY
1
4
026-01X3377
REAR UPRIGHT RIGHT ASSEMBLY
1
5
026-01X3305
WEIGHT HORN ASSEMBLY
2
6
026-01X3536
SHAFT, ROCKING LINK
1
7
026-01X3638
CENTER UPRIGHT
1
8
026-01X3639
BASE FRAME ASSEMBLY
1
9
026-01X3640
LIFT ARM
1
10
026-01X3641
FOOTPLATE ASSY.
1
11
026-01X3642
ACTUATING LINK
1
12
026-01X3643
PULL-LINK
1
13
026-01X3644
ROM ASSY. CALF RAISE
1
14
026-01X3645
PRESS ARM
1
15
026-01X3646
HEIGHT ADJUSTER OUTER
1
16
026-01X3648
REAR FOOT
1
17
026-01X3649
SHOULDER PAD MOUNT LEFT
1
18
026-01X3650
SHOULDER PAD MOUNT RIGHT
1
19
026-01X5186
LEVELING FOOT (M16X2.0)
1
20
011-0111008
SET SCREW: 1/4"-28 X .25" LG. (WZ)
4
21
012-0103001
16M X 2.0 FLANGED NUT (WZ)
1
22
014-0012013
BEARING: BALL BEARING Ø2.44" O.D. X Ø1.18" I.D.
2
23
014-0012014
FLANGELESS BEARING - 25mm I.D.
8
24
014-0012018
SNAP RING - 25mm EXTERNAL
6
25
014-0012015
FLANGELESS BEARING
1.6535 O.D. X
.79 I.D. X .4724 WIDE
4
26
014-0012017
SNAP RING - 20mm EXTERNAL
4
27
014-0012019
SNAP RING - 30mm EXTERNAL
2
28
014-0019005-1
T SPLIT COLLAR THREADED 1.00" I.D. X 20mm
1
29
014-0101017
BUSHING: OILITE FLANGED Ø1.00" ID X Ø1.38" OD X .75" LG.
4
30
016-0001003
END CAP 1.50" X 2.50" (BLACK)
2
31
016-0101004-B
1.50" X 1.50" END CAP (BLACK)
1
32
019-0001001
PLUG BUMPER
1
33
026-01F0251
BRACKET PLATE: 2 HOLES 7.00" X 2.75"
1
34
026-01M0932
ALUMINIUM CAP: Ø1.25" ID
2
35
026-01M0933
ALUMINUM RING: Ø1.25" ID
2
PART LIST
RPL-5405 ASSEMBLY
OWNER'S MANUAL
PAGE 27
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
