Hoist Fitness CF-3754 - Manual (Page 25)

ITEM NO. PART NUMBER DESCRIPTION QTY.
1 026-01X2934 VERTICAL GUIDE, RIGHT 1
2 026-01X2935 VERTICAL GUIDE, LEFT 1
3 026-01X2936 SHAFT MOUNT ASSEMBLY 2
4 026-01X2971 CROSS MEMBER ASSEMBLY 1
5 026-01X3129 REAR UPRIGHT 2
6 026-01X3245 CROSSMEMBER, UPPER 1
7 026-01X3246 CROSSMEMBER, LOWER 1
8 026-01X5313 BASE ASSEMBLY-2 1
9 026-01X5314 BASE ASSEMBLY-1 1
10 026-01X5365 MIDDLE UPRIGHT-1 1
11 026-01X5370 MIDDLE UPRIGHT-2 1
12 026-01X5375 SAFETY BAR 2
13 026-01X5379 SAFETY BAR STORAGE 2
14 026-01X5380 FRONT UPRIGHT-2 2
15 026-01X5417 WEIGHT HORN 2
16 026-01X5418 WEIGHT BAR 1
17 014-0007007 BEARING 25mm (LINEAR) (WON) 4
18 014-0007008 BEARING 25MM (LINEAR BLOCK) 2
19 014-0007011 BEARING 30MM (LINEAR) (WON) 4
20 014-0012014 FLANGELESS BEARING - 25mm I.D. 4
21 014-0015005 SNAP RING: Ø40mm INTERNAL 4
22 014-0015036 RETAINING RING: 52mm INTERNAL 2
23 014-0023010 SNAP RING: Ø47mm INTERNAL 4
24 016-0201009 END CAP 1.50" X 3.00" (BLACK) 2
25 019-0001012 BUMPER 2.00" OD X 1.02" ID X .50" THICK 2
26 019-0002034 GRIP - CLOSED END 1.50" X 4.50" LG. 2
27 026-01G0197 GUIDE ROD 75.44" LG. 2
28 026-01G0218 GUIDE ROD 46.25" LG. 2
29 026-01G0220 GUIDE ROD 37.75" LG. 2
30 026-01M2278 WEIGHT PEG 12.38" LG. 2
31 026-01M2473 WEIGHT PEG 17.25" LG. 4
32 026-01M2496 SHAFT 1.14" X 49.56 2
33 026-01P2380 WASHER 3.00 2
34 026-01P2737 CAP 2
35 026-01P3089 SIDE PLATE 2
PARTS LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
OWNER'S MANUAL
CF-3754 ASSEMBLY PAGE 24
